Features

Flexible functionality, minimizing your resources

• Provides flexibility in cabinet mounting options and functionality including I/O and fieldbus communications
• The F300 is a flexible solution for panel mounting, integration into systems and wall mounting in clean environments. Automation centres can provide built-to-order cabinet solutions, ideally matching customer requirements.
• Comprehensive on-board drive programming available for fan, pump and compressor applications
• On-board PLC provides extensive IEC 61131-3 compliant programming functionality without the additional cost
• Optimum energy efficiency
• Best in class efficiency from matched motor and drive combinations
• Enables conformance with the latest EC efficiency regulations through the control of AC induction motors and Ultra Efficient IE4 PM/ Super Nema Premium Motors.

Ease and speed of design, build and commissioning

• Smaller drive dimensions to allow for easier, more economical installation
• Programming software enables rapid, clear code development and the drive interface and PC tools also allow fast, simple drive commissioning, diagnostics and maintenance
• Equipped with wide motor control functionality flexible to ventilation, pumping and compression application needs, which can be rapidly accessed to exacting levels of flow control
• Comprehensive I/O offering boosts component connectivity
• Multiple fieldbus protocols are supported
• Wide power range from 1.1kW through to 2.8MW  to suit your fan, pump and compressor rating
• ​Fan and pump macros with PC Tools provide fast, simple access to flow performance
• Two PID Controllers with anti-windup and user scaling provide flow-specific functionality
• Logic functions including 'and' , 'or', 'invert', 'binary sum' and 'timer' achieved through easy menu setup
• Real-time clock available on the KI-HOA Keypad RTC included in standard offer
• Water hammer control with S-ramp deceleration
• Catch a spinning motor
• On-board Fire Mode allowing run to failure in the event of a fire for the extraction of smoke
• Low load condition monitoring and hysteresis for broken belt and dry pump detection

Flexible I/O range

• I/O specific to pumping, ventilation and compression application
  • 2 x analog input, 2 x analog output, 3 x digital input,
  • 3 x configurable digital output; 2 x form C relay output,
  • 1 x Safe Torque Off input

Safe Torque Off

• Safe Torque Off functionality can remove the need for a contactor and can avoid a complete power-down for safe access to machinery

Harmonics and drive conformance

• Low harmonic emissions and achieves high conformance levels.



Specifications

​Key data

• 1.1 kW – 2.8 MW (1.5 - 4,200 hp)
• Supply phases: 3 phase

• Onboard PLC

Onboard comms:

• RS485

Safety:

• 1 x Safe Torque Off (STO) terminal
• SIL3/PLe compliant

• Hand-Off-Auto control keypad as standard

• 3

Parameter cloning via:

• PC tools
• Smartcard
• SD card



VOLTAGE RATINGS​ ​
100 V (100 V - 120 V ± 10%)	​
​200 V (200 V - 240 V ± 10%)	​✓
​400 V (380 V - 480 V ± 10%)	​✓
​575 V (500 V - 575 V ± 10%)	​✓
​690 V (500 V - 690 V ± 10%)	​✓



CONTROL MODE​ ​
​Open loop vector or V/Hz induction motor control	✓​
​Open loop Rotor Flux Control for induction motors (RFC-A)	​✓
​Open loop permanent magnet motor control (RFC-S)	✓​



SINGLE DRIVES:

FRAME SIZE​	DIMENSIONS (H X W X D)​ ​		​WEIGHT KG(LB) ​
​	​mm	​in	​kg	​lb
​3	​365 x 83 x 200	​14.4 x 3.3 x 7.9	​4.5 Max	​9.9 Max
​4	365 x 124 x 200	​14.4 x 4.9 x 7.9	​6.5	​14.3
​5	​365 x 143 x 200	​14.4 x 5.6 x 7.6	​7.4	​16.3
​6	365 x 210 x 227	​14.4 x 8.3 x 8.9	​14	​30.9
​7	​508 x 270 x 280	​20 x 10.6 x 11.0	​28	​61.7
​8	​753 x 310 x 290	​29.7 x 12.2 x 11.4	​52	​114.6
​9A	​1049 x 310 x 290	​41.3 x 12.2 x 11.4	​66.5	​146.6
​​9E | 9T †	​1010 x 310 x 290​	​41.3 x 12.2 x 11.4​	​46	​101.4
​​10E | 10T †	​1010 x 310 x 290	​​41.3 x 12.2 x 11.4	​46	​101.4
​11E | 11T †	​1190 x 310 x 312	​46.9 x 12.2 x 12.3	​63	​139.8

 Dimensions include mounting brackets.

† Internal line choke not included



MODULAR DRIVES:

FRAME SIZE	DIMENSIONS (H X W X D)
	mm	in
INVERTER
9D	773 x 310 x 290	30.4 x 12.2 x 11.4
10D	773 x 310 x 290	30.4 x 12.2 x 11.4
11D	863 x 310 x 312	34 x 12.2 x 12.3
RECTIFIER
10A	6 pulse 355 x 310 x 290	6 pulse 15.8 x 12.2 x 11.4
11A | 11T	6 pulse 415 x 310 x 290 12 pulse 415 x 310 x 290	6 pulse 16.3 x 12.2 x 11.4 12 pulse 16.3 x 12.2 x 11.4

Dimensions include mounting brackets.

† Internal line choke not included



Options

Keypads

	KI-HOA Keypad RTC The KI-HOA Keypad RTC provides Hand-Off-Auto control. The display presents up to four lines of real text with multi-language translation, enhancing clarity and increasing ease of use. A battery operated realtime clock allows accurate time stamping of diagnostics and aids quick fault resolution.
	Remote keypad All the features of the CI-Keypad LCD, but remote mountable. This allows flexible mounting on the outside of a panel and meets IP66 (NEMA 4)

System Integration Modules - Communications

	SI-PROFIBUS PROFIBUS-DP (Decentralized Peripheral) interface module enables follower connectivity. It is possible to use more than one SI-PROFIBUS or a combination of SI-PROFIBUS and other option modules to add additional functionality such as extended I/O, gateway functionality, or additional PLC features.
	SI-DeviceNet DeviceNet networking system interface module enables follower connectivity. It is possible to use more than one SI-DeviceNet or a combination of SI-DeviceNet and other option modules to provide additional functionality such as extended I/O, gateway functionality, or additional PLC features.
	SI-CANopen CANopen interface module supporting various profiles, including several drive profiles
	SI-Ethernet External Ethernet module that supports PROFINET RT*, EtherNet/IP and Modbus TCP/IP and has an integrated web server that can generate emails. The module can be used to provide high speed drive access, global connectivity and integration with IT network technologies, such as wireless networking
	SI-PROFINET RT PROFINET RT interface modulePROFINET RT interface module provides fast, high-precision communications for maximum plant productivity. Dual port cable connection ensures rapid and easy installation. PROFINET is an Ethernet based industrial network protocol adapting Ethernet hardware to the real time needs of industrial automation.

System Integration Modules - Additional I/O

SI-I/O Extended I/O interface module to increase the number of I/O points on a drive. Provides additional: 4 x Digital I/O, 3 x Analog inputs (default)/Digital inputs, 1 x Analog output (default)/Digital input, 2 x Relays

Drive interface units - Back-up



	Smartcard The optional Smartcard memory device can be used to back-up parameter sets and basic PLC programs, as well as copying them from one drive to another
	SD Card Adaptor Conversion device that allows an SD card to be inserted into the Smartcard slot, for parameter cloning and application programs

Drive interface units - Communications

	KI-485 Adaptor This allows the drive to communicate via RS485. This is commonly used for programming if the drive has no keypad
​	​CT USB Comms Cable The USB Comms Cable provides PC connectivity to the drive, enabling drive configuration with the Connect PC Tool. Use of the Connect PC Tool is recommended for setup of LSRPM motors. Drives with Ethernet support PC connectivity via a standard Ethernet cable.

Powerdrive F300 Model
