PLC LS MASTER-K
Powerful & compact block-type PLC CPU, digital I/O and power part are embedded in block-type PLCs, which is very compact and easy to install in area you want for system configuration. Also through various built-in function, user can configure cost-effective system.
K80S Features
Compact and high-function block type
- - Base: 10, 20, 30, 40, 60 points
- - Expansion: 10, 20 points
Various built-in functions for applications
- - HSC 1 point, Pulse output 1 point
- - PID (Max. 8 loops), Pulse catch 8 points
- - Built-in RS-232C I/F 1Ch: 4 (Rx), 7 (Tx), 5 (SG)
Various applications with special/comm. modules
- - Analog input/output: G7F-ADHA
- - Analog input: G7F-AD2A
- - Analog timer: G7F-AT2A
- - Cnet I/F: RS-232C, RS-422
- - Fnet (Master)/Rnet (Master)
- - Profibus-DP (Slave)/DeviceNet (Slave)
- - RTC/Memory pack
On-line edit in KGL WIN
K120S Features
High-performance and various block type
- - Economic type: 10/14/20/30 points (10/14 points: 2points built-in Analog Timer)
- - Standard type: 20/30/40/60 points
- - Various expansion modules: input, output, mixed modules
- - P area extended for SMART I/O application (P000~P63F)
- - High-speed processing speed: 0.1㎲/step (standard type)
- - Battery-less backup
- - Program backup: EEPROM backup while online editing
- - Data backup: Super capacitor
- - Various input handing: Input filter, pulse catch
Enhanced communication functions
- - Built-in RS-232C (Ch0) and RS-485 (Ch1) support *1)
- - Transmitting data monitoring support: KGLWIN
- - Various option modules
- - Cnet (RS-232C, RS-422) Fnet/Rnet (master module)
- - Profibus-DP/DeviceNet (slave module)
Powerful built-in functions
- - High-speed counter: 32-bit signed operation
- - Counter range: -2,147,483,648 ~ 2,147,483,647
- - Function: ring counter, latch counter, comparison (equal/zone/task), RPM
- - Positioning function (DRT/DT type)
- - Control axis: 2 axes (100kHz)
- - Operation method: single, repeat
- - Operation mode: end, keep, continuous
- - Additional functions: return to origin, JOG operation, PWM output
- - PID operation function
- - Relay/PRC auto-tuning, SV ramp, delta MV, PWM output, position/velocity algorithm
Various expansion modules
- - 7 Digital I/O modules: G7E-DR(08/10/20)A, G7E-TR10A, G7E-DC08A, G7E-RY(08/16)A
- - 9 Analog I/O modules: G7F-ADHA(B/C), G7F-AD2A(B), G7F-DA2I(V), G7F-AT2A, G7F-RD2A
- - 6 Comm. modules: G7L-CUEB(C), G7L-DBEA, G7L-PBEA, G7L-FUEA, G7L-RUEA
- - 2 Option modules: G7E-RTCA, G7M-M256B
