** PLC DELTA ขนาดเล็ก เหมาะสำหรับ งานเครื่องจักรขนาดเล็กถึงขนาดกลาง

ES2 series is a small PLC for basic sequential control. It is economical, highly efficient and functional.



Specifications

   MPU points: 16 / 20 / 24 / 32 / 40 / 60

   Program capacity: 16k steps

   Built-in with 3 COM ports: 1 RS-232 port and 2 RS-485 ports, all are able to operate independently (Master/Slave)

   Max. I/O points: 256 input points + 16 output points, or 256 output points + 16 input points

   DVP-EX2 MPU is built in with 12-bit 4AD/2DA and offers analog/temperature modules of 14-bit resolution.

   Built-in with 8 high-speed input points (2 points for 100kHz, 6 points for 10kHz) and supports U/D, U/D Dir, A/B counting modes

   New motion control instructions: Close loop control, alignment mark, shield, immediate variable speed, S-Curve acceleration/deceleration

   Application in emerging industry: Exclusive instructions and function blocks designed for PV solar tracker

   Handy instructions for frequency inverter: For controlling the forward running, reverse running, RUN and STOP of Delta@@s AC motor drives

   Password protection: Password for subroutine, user ID, restriction on trial times

   Highly efficient instruction efficient instruction execution

ES2/EX2 Model
