FRENIC-AQUA is the first slim type inverter dedicated for a variety of applications of water supply and wastewater treatment system from Fuji Electric. This new series follows European trends keeping high Japanese reliability. Specific functions to prevent damage on the systems and new energy saving functions are installed as standard, positioning FRENIC-AQUA as a high performance inverter on the pumping application market.

How to read the model number

Model variation

Destination	Rated voltage	Nominal applied motor	Type
Europe /Asia/China (E/A/C)	3-phase 400V	0.75	FRN0.75AQ1□-4#
		1.5	FRN1.5AQ1□-4#
		2.2	FRN2.2AQ1□-4#
		3.7	FRN3.7AQ1□-4#
		5.5	FRN5.5AQ1□-4#
		7.5	FRN7.5AQ1□-4#
		11	FRN11AQ1□-4#
		15	FRN15AQ1□-4#
		18.5	FRN18.5AQ1□-4#
		22	FRN22AQ1□-4#
		30	FRN30AQ1□-4#
		37	FRN37AQ1□-4#
		45	FRN45AQ1□-4#
		55	FRN55AQ1□-4#
		75	FRN75AQ1□-4#
		90	FRN90AQ1□-4#
		110	FRN110AQ1□-4#
		132	FRN132AQ1□-4#
		160	FRN160AQ1□-4#
		200	FRN200AQ1□-4#
		220	FRN220AQ1□-4#
		280	FRN280AQ1□-4#
		315	FRN315AQ1□-4#
		355	FRN355AQ1□-4#
		400	FRN400AQ1□-4#
		500	FRN500AQ1□-4#
		630	FRN630AQ1□-4#
		710	FRN710AQ1□-4#

□(Protective structure) : M : IP21, L : IP55(0.75 to 90kW), S : IP00(110 to 710kW)
#(Destination) : A : Asia, E : Europe, C : China

Features

• Wide capacity range from 0.75 kW to 710 kW
• IP21 & IP55 with same dimension
• DCR Reactor and EMC filter built-in up 90 kW. Built-in EMC filter for all capacities
• Overload capability 110%
• Torque Vector control
• Modbus RTU, BACnet MS/TP, Metasys N2; integrated as standard
• Large LCD display, 19 languages + user customizable language
• Specific macros for common fan and compressor applications
• Customizable Logic (mini PLC), 14 steps, possibility to manage digital and also analog signals
• Real Time Clock (RTC)
• 4 PID sets
• Unit conversion function (kPa, bar, l/min, etc.)
• Fire mode (forced operation)
• Catch spinning motor
• Password function
• New energy saving functions (sleep mode)
• Multipump control (up to 9 pumps with one inverter)
• Anti jam function
• Pipe fill mode
• Extension cable for remote operation (CB-…S)
• Battery (OPK-BP)

Option cards

Fieldbus options:

• CC-Link communications card (OPC-CCL)
• DeviceNet communications card (OPC-DEV)
• PROFIBUS DP communications card (OPC-PDP2)
• CANopen communications card (OPC-COP)
• LonWorks communications card (OPC-LNW)
• Ethernet communications card (OPC-ETH)

Other options:

• Relay output interface card (2 outputs) (OPC-RY)
• Relay output interface card (7 outputs) (OPC-RY2)
• Analog input interface card (OPC-AIO)
• Analog current output interface card (OPC-AO)
• Pt100 temperature sensor input card (OPC-PT)



Standard Specifications

3-phase, 400V series (0.75 to 55kW)

3-phase, 400V series (75 to 710kW)

AQUA (FRN-AQ) Model
